Gabions consist of rectangular units, fabricated from a double-twisted hexagonal mesh. Filled with stones, gabions become large, flexible and permeable elements from which a broad range of structures may be built.
Usage
Gabion mesh box used in Control and guide of water or flood , Preventing of rock breaking ,Keep off dust wall; Gabion mesh box used in Rock fall protection ,Water and soil protection , Port project, roadway protection; Gabion mesh box used in Bridge protection ,Strengthening structure of so Protection engineering of seaside area.
General specifications:
| Sizes | Amount of diaph ragm | Standard | Spiral Spindle | ||||||||||
| L*W*H | 300*100 | 300*50 | 200*100 | 200*50 | 150*100 | 150*50 | 100*100 | 100*50 | 50*50 | 150 | 100 | 50 | |
| 300x100x100 | 0 | 4 | 2 | 8 | 8 | ||||||||
| 2 | 4 | 4 | 8 | 16 | 4 | ||||||||
| 300x100x50 | 0 | 2 | 2 | 2 | 8 | 4 | 4 | ||||||
| 2 | 2 | 2 | 4 | 8 | 8 | 8 | |||||||
| 300x50x100 | 0 | 2 | 2 | 2 | 8 | 4 | 4 | ||||||
| 2 | 2 | 2 | 4 | 8 | 8 | 8 | |||||||
| 300x50x50 | 0 | 4 | 2 | 8 | 16 | ||||||||
| 2 | 4 | 4 | 8 | 8 | |||||||||
| 200x100x100 | 0 | 4 | 2 | 16 | |||||||||
| 1 | 4 | 3 | 20 | ||||||||||
| 200x100x50 | 0 | 2 | 2 | 2 | 12 | 4 | |||||||
| 1 | 2 | 2 | 3 | 14 | 6 | ||||||||
| Mesh sizes | Numbers of diaphragm | Approximate dimensions and volumes | Tolerance | Colour code | Wire diameter(mm) | |||
| Length(m) | Width(m) | Depth(m) | Capacity(m³) | |||||
| 60*80 80*100 80*120 100*120 120*150 | 1 | 2.00 | 1.00 | 0.30 | 0.60 | Length±5% Width±5% Depth±5% | Blue Red Green Black | Heavily galvanized or galfan coated wire 2.00-3.00Or PVC coated on heavily galvanized or galfan coated wire 2.0/3.0, 2.2/3.2, 2.4/3.4, 2.7/3.7, 2.0/4.0. |
| 1 | 2.00 | 1.00 | 0.50 | 1.00 | ||||
| 1 | 2.00 | 1.00 | 1.00 | 2.00 | ||||
| 2 | 3.00 | 1.00 | 0.30 | 0.90 | ||||
| 2 | 3.00 | 1.00 | 0.50 | 1.50 | ||||
| 2 | 3.00 | 1.00 | 1.00 | 3.00 | ||||
| 3 | 4.00 | 1.00 | 0.30 | 1.20 | ||||
| 3 | 4.00 | 1.00 | 0.50 | 2.00 | ||||
| 3 | 4.00 | 1.00 | 1.00 | 4.00 | ||||
| 1 | 2.00 | 0.50 | 0.50 | 0.50 | ||||
| 2 | 3.00 | 0.50 | 0.50 | 0.75 | ||||
